起订:100000pcs
供应:100000pcs
发送询价
额定电流 1.0（A） 额定电压 125（V） 环境温度 -40~80（℃） 壳体材质 PBT 导电体材质 CU 产品认证 UL MATERIAL 1. HOUSING MATERIAL : GLASS FILLED PLYESTER UL94V-0PBT、 NYLON2. HOUSING COLOR : BLACK OR OTHERS3. ConTACT MATERIAL : PHOSPHOR BRonZE φ0.46mm4. PLATING: GOLD PLATING OVER NICKEL.GOLD PLATINGTHICKNESS 1.5u"/3u"/6u"/15u"/30u"/50u" SPECIFICATIONS ELECTRICAL1. VOLTAGE RATING: 125 VAC RMS.2. CURRENT RATING: 1.0 AMP3. ConTACT RESISTANCE: 30 MILLIOHMS MAX.4. INSULATION RESISTANCE : 500 MEGOHMS MIN ＠500 VDC5. DIELECTRIC WITHSTANDING RESISTANCE: 1000 VAC RMS.50Hz 1MINUTEMECHANICAL1. DURABILITY : 750 CYCLES MIN2. PCB RETENTION PRE-SOLDER: 1 LB MINENVIRONMENTAL1. STORAGE :-40℃~80℃2. OPERATION: 0℃~70℃
