起订:5000pcs
供应:20000pcs
发送询价
r r r r r 额定电流r r r 1.5（A）r r r 额定电压r r r 150（V）r r r r r 环境温度r r r -40~80（℃）r r r 壳体材质r r r ABSr r r r r 导电体材质r r r 铜r r r 产品认证r r r ULr r r r rMATERIAL 1. HOUSING MATERIAL : GLASS FILLED PLYESTER UL94V-0PBT、NYLON2. HOUSING COLOR : BLACK OR OTHERS3. ConTACT MATERIAL : PHOSPHOR BRonZE φ0.46mm4. PLATING: GOLD PLATING OVER NICKEL.GOLD PLATINGTHICKNESS 1.5u"/3u"/6u"/15u"/30u"/50u" SPECIFICATIONS ELECTRICAL1. VOLTAGE RATING: 125 VAC RMS.2. CURRENT RATING: 1.5 AMP3. ConTACT RESISTANCE: 30 MILLIOHMS MAX.4. INSULATION RESISTANCE : 500 MEGOHMS MIN＠500 VDC5. DIELECTRIC WITHSTANDING RESISTANCE: 1000 VAC RMS.50Hz 1MINUTEMECHANICAL1. DURABILITY : 750 CYCLES MIN2. PCB RETENTION PRE-SOLDER: 1 LB MINENVIRONMENTAL1. STORAGE :-40℃~80℃2. OPERATION: 0℃~70℃ r
