Electrical:
Current Rating:1.5AMPS
Voltacge Rating:125VAC
Insulation Resistance:500MΩ Min
Withstand Voltage:AC 1500V AC 1500V 50Hz o60Hz 6s
Contact Resistance:20mΩ Max
Mechanical:
Mating Force:2.2KG.F Max
Retention Strength:7.7Kg Between jack and plug
Durability:750Mating cycles Mini
MATERIAL:
Housing: ABS(UL94V-0)
Gold Needle: Phosphobronze aftefirst nickel plating gold-plated
